Page 18
18
American Dryer Corporation
450343 - 4
Front Panel Assembly
For Models Mfd. with Plastic Main Door
Illus. No.
Part No.
Qty.
Description
1
882525
1
White Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
882527
1
Almond B Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
882528
1
Coral Blue Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
2
150309
11
#10-16 x 1/2” Hex Head TEK Crimptite Screw
3
121405
1
Rubber Grommet
4
––––––
1
Lint Drawer Switch
(refer to Lint Drawer / Lint Drawer Switch Assemblies on page 30 and page 31)
5
170330
1
Friction Door Latch
6
154215
2
5/32” Pop Rivet
