User's Guide HDSP System Multiface II
© RME
21
10. Operation under ASIO
10.1 General
Start the ASIO software and select ASIO Hammerfall DSP as the audio I/O device.
The Multiface supports ASIO Direct Monitoring (ADM).
The Multiface’s MIDI I/O can be used with both MME MIDI and DirectMusic MIDI.
10.2 Channel Count under ASIO
At a sample rate of 88.2 or 96 kHz, the ADAT optical input and output operate in S/MUX mode,
so the number of available channels per port is reduced from 8 to 4.
Note: When changing the sample rate range between Single and Double Speed the number of
channels presented from the ASIO driver will change too. This may require a reset of the I/O list
in the audio software.
Single Speed
Double Speed
Analog 1 to 8
Analog 1 to 8
SPDIF L / R
SPDIF L / R
ADAT 1 to 8
ADAT 1 to 4
