12
CUT 250 CUT 250 CUT 250 CUT 250 CUT 250
10
46 ........................................ Blade
47 ........................................ Blade shaft flange stakes
48 ........................................ Blade shaft flange
49 ........................................ Screw M12
50 ........................................ Fixed guard
51 ........................................ Grain M16
52 ........................................ Coolant tube
53 ........................................ Mobile guard
54 ........................................ Ring seeger Ø 60 E
55 ........................................ Screw M6
57 ........................................ Mobile guard rod
58 ........................................ Ring seeger Ø 10 E
59 ........................................ Tie rod support pin
60 ........................................ Tie rod support
61 ........................................ Screw M8
62 ........................................ Pin Ø 4
63 ........................................ Worm wheel
64 ........................................ Grain M8
65 ........................................ Worm wheel retaining washer
66 ........................................ Screw M12
67 ........................................ Ring nut M17
68 ........................................ Worm screw
69 ........................................ Ring DPSM 25-47-7
70 ........................................ Front flange
71 ........................................ Stud bolt
72 ........................................ Washer
73 ........................................ Nut M16
74 ........................................ Bearing 6025 2rs
75 ........................................ Motor shaft (rotor)
76 ........................................ Key
77 ........................................ Motor housing and stator
78 ........................................
79 ........................................ Head gasket
80 ........................................
82 ........................................ Motor head
83 ........................................ Motor rear flange
84 ........................................ Fan
85 ........................................ Fan cover
86 ........................................ Screw M4
87 ........................................ Bearing 609
88 ........................................ Pump connexion box
89 ........................................ Screw M5
90 ........................................ Coolant pump
91 ........................................ Screw M6
92 ........................................ Oil level-drain plug
93 ........................................ Return spring connection
94 ........................................ Head return spring
............................................
1 .......................................... Machine bed
2 .......................................... Revolving arm
3 .......................................... Revolving arm locking pin
4 .......................................... Revolving arm locking bush
5 .......................................... Revolving arm locking lever
6 .......................................... Screw M8
7 .......................................... Pin Ø 6
8 .......................................... Countervice
9 .......................................... Grain M6
10 ........................................ Bar stop rod
11 ........................................ Bar stop
12 ........................................ Vice
13 ........................................
14 ........................................
15 ........................................
16 ........................................
17 ........................................ Oiler Ø 5
18 ........................................ Vice handwheel
19 ........................................ Pin Ø 6
20 ........................................ Vice thread
21 ........................................
22 ........................................
23 ........................................ Burr-free plate
24 ........................................ Seal filter support flange
25 ........................................ Ring seeger Ø 42 I
26 ........................................ Tank cover filter
27 ........................................ Filter support flange
28 ........................................ Screw M5
29 ........................................ Washer
30 ........................................ Coolant tap
31 ........................................ Coolant tube
32 ......................................... Screw M6
33 ........................................ Tank filter
34 ........................................ Screw M8
35 ........................................ Nut M8
36 ........................................ Hinge pin
37 ........................................ Grain M6
38 ........................................ Nut M6
39 ........................................
40 ........................................ Nut M16
41 ........................................ Head lever
42 ........................................ Head lever handgrip
43 ........................................ Ring SM 30-40-7
44 ........................................ Key 8x7x30
45 ........................................ Blade shaft
MACHINE COMPONENTS
10.1 - List of spare parts
REFERENCE N DESCRIPTION REFERENCE N DESCRIPTION
