Ab b – Aussie 68R5A9SSS1 User Manual
Page 7
7
Step 5
A. Cabinet Upright Assembly
Attach Cabinet Upright to Cabinet Bottom and Front Crossbar with four 5/32 x .31” Bolts. Orient Upright so that Match
holder/Chain is closest to top of cabinet (Front Crossbar).
B. Front Corner Bracket Assembly
Attach Front Corner Brackets to Cabinet Bottom Panel and Left and Right Side Panels with eight 1/4-20 x .5” bolts. Flat
side of Bracket should be to front of cabinet so it is flush with front edges.
Step 4
Front Crossbar Assembly
Turn cart assembly up on casters. Attach Front Crossbar, with the triangle braces facing down and the flat surface to
the front, to Side Panels with six 1/4-20 x .50” Bolts into the threaded holes in the top inside ends of Side Panels.
front crossbar
5/32 x .31” Bolt set
4 pc
1/4-20 x .50” Bolt set
6 pc
A
B
B
1/4-20 x .50” Bolt set
8 pc
Front Corner Bracket
Cabinet Upright
