38
Parts List- Model 6805
Key Description Quantity
1 Side Burner Cover 1
2 Main Burner 4
3 Side Burner Cooking Grid 1
4 Left Side Table 1
5 Side Burner Valve 1
6 Side Burner Knob Bezel 1
7 Control Knob 7
8 Cast Iron Side Burner 1
8A Side Burner Bracket 1
8B Side Burner Wind Shield 1
9 Manifold Assembly 1
10 Ignition Box 1
11 Control Panel 1
12 Main Knob Bezel 6
13 Front Crossbar 1
14 Back Panel Brace wire 1
15 Cabinet Side Panel- LEFT 1
16 Cabinet Upright 1
17 Cylinder Retainer Bolt 1
18 Cabinet Bottom Panel 1
19 Cabinet Door- LEFT 1
20 Cabinet Door- RIGHT 1
21 Handle, Door/Drawer 3
22 Hood Handle 1
23 Thermometer 1
23A Thermometer Bezel 1
24 Hood Bumper 2
25 Hood 1
26 Warming Rack 1
27 Main Cooking Grid 3
28 Small Flavor Activator 3
28A Large Flavor Activator 4
29 Rotisserie Burner 1
30 Sear Burner 1
31 Right Side Table 1
32 Main Electrode Assembly 2
33 Tool Hooks 3
34 Bottom Body Panel 1
35 Foil Pan 1
36 Grease Pan 1
37 Cabinet Back Panel 1
38 Drawer Tracks 2
39 Cylinder Blocking Wire 1
40 Cabinet Side Panel- RIGHT 1
41 Match Holder/Chain 1
42 Drawer Body 1
43 Drawer Front 1
44 Caster, Fixed 2
45 Caster, Locking Swivel 2
46 Manifold - SB valve Hose 1
46A Regulator 1
47 Center Wheel 1
48 Front Corner Bracket 2
49 1/4-20 x .50” S/S Bolt 36
50 1/4-20 S/S Hex Nut 10
51 1/4-20 x .60” S/S Bolt 16
52 5/32 x .47” S/S Bolt 4
53 5/32 x .31” S/S Bolt 38
54 5/32 S/S Hex Nut 1
55 Thermocouple - Rotisserie 1 (no pic)
56 Side Burner Electrode 1 (no pic)
57 Sear Burner Electrode 1 (no pic)
58 Rotisserie Electrode 1 (no pic)
