Chapter 3 69
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Screw List
Item Screw Color Part No.
A M2 x L3 Silver 86.9A552.3R0
B M2 x L4 Silver 86.9A552.4R0
C M2.5 x L5 Black 86.00E33.736
D M2 x L8 Black 86.00E34.738
F M2 x L3 Silver 86.00E13.524
H M2 x L3 Silver 86.00C07.220
MAIN UNIT
KEYBOARD
MAIN
BOARD
Bx3
MAIN UNIT DISASSEMBLY
LCD MODULE
B x 2
Bx2, Dx2
UPPER CASE
C x 14
CPU/VGA
THERMAL MODULE
CPU
SCREW X 5 (CPU)
MODEM
BOARD
MODULE
HEAT SINK FAN
TOUCHPAD
BRACKET
MIDDLE COVER
VGA CARD
SCREW X 4 (VGA)
B x 2
POWER
BOARD
SPEAKER
MODULE
H x 2 F x 2, Ax1 A x 1
LAUNCH
BOARD
TOUCHPAD
MODULE
FINGERPRINT
MODULE
A x 2
Ax1
B x 2
USB
BOARD
MODULE
B x 1
