LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Item
Screw
Color
Part No.
B
M2 x L4
Silver
86.9A552.4R0
C
M2.5 x L5
Black
86.00E33.736
G
M2.5 x L5
Black
86.00F87.735
LCD MODULE
LCD BEZEL
Cx4
LCD ASSEMBLY
LEFT LCD
BRACKET
Bx2
RIGHT LCD
BRACKET
Bx2
LCD FPC
CABLE
LCD BACK PANEL
ANTENNAS
LCD MODULE DISASSEMBLY
Gx6, B2
VGA
CAMERA
