ELECTRICAL REPLACEMENT PARTS LIST
REF.NO. PART NO. DESCRIPTION
*** CRYSTAL & CERAMIC OSCILLATORS ***
X1001 S0-0CT-012-070 X'TAL,HC-49/U-S
X1002 S0-0D3-2R8-010 X'TAL,32.768K
X4001 S0-0CF-4R4-010 X'TAL,HC-49/U
X6601 S0-0CT-024-010 X'TAL,HC-49/U
*** TUNER ***
! TU6001 S1-626-070-100 RF UNIT,TMDB2-103A
*** FUSES ***
! F501 S8-0PT-1R6-020 FUSE,21801.6
FH501 S6-710-T00-060 HOLDER,FUSE EYF-52B
FH502 S6-710-T00-060 HOLDER,FUSE EYF-52B
*** OTHERS ***
CP1001 S6-CH2-207-6A0 CORD CONN CH22076A
OS651 S7-710-000-130 REMOTE RECEIV PNA4612M00Y
V651 S9-677-9R0-050 FL,DISPLAY 7-MT-201GA
OPERATION 1 PCB ASS'Y
*** SWITCHES ***
SW601 S5-042-01T-320 SW,TACT
SW602 S5-042-01T-320 SW,TACT
SW603 S5-042-01T-320 SW,TACT
SW604 S5-042-01T-320 SW,TACT
SW605 S5-042-01T-320 SW,TACT
SW606 S5-042-01T-320 SW,TACT
OPERATION 2 PCB ASS'Y
*** DIODE ***
D601 S0-213-5Q1-600 LED,SLZ-345B-02
*** TRANSISTOR ***
Q601 87-026-286-010 TR,DTA143ES
*** SWITCHES ***
SW607 S5-042-01T-320 SW,TACT
SW608 S5-042-01T-320 SW,TACT
SW609 S5-042-01T-320 SW,TACT
SW610 S5-042-01T-320 SW,TACT
*** OTHER ***
CD602 S6-CH2-508-2A0 CORD CONN CH25082A
AND OTHERS
*** AC CORD ***
! CD501 S2-066-358-170 CORD AC BUSH 06635817
N-3
