2. Operation
2.1 Record/Play Modes
• If the “PLAY” light is OFF, the multiplexer is in RECORD mode. This mode is used for
recording the camera images onto tape. Make sure that the VCR is also in “RECORD” mode.
• If the “PLAY” light is ON, the multiplexer is in PLAY mode. This mode is used to replay
images from tape. Make sure that the VCR is also in “PLAY” mode.
Press the PLAY key to change mode. To enter PLAY mode, the PLAY key must be pressed for at
least 1 second.
2.2 VCR View Mode
If the “VCR VIEW” light is ON, the multiplexer is in “VCR VIEW” mode.
The “VCR VIEW” mode allows the output of the VCR to be directly viewed. If the VCR and
Multiplexer are both in “RECORD” mode, “VCR VIEW” mode allows the rapidly multiplexed
images to be seen on the Monitor “A”. This provides a confidence check that multiplexing is taking
place and that all cables are correctly connected. It also allows the clock/calendar of the VCR to be
viewed and/or set.
Press the “VCR VIEW” key to change mode.
2.3 Display Options
This table summarises the display options of the different multiplexers:
Multiplexer Models Full
Screen
Quad Dual
Quads
12-
way
multi
screen
16-way multi
screen
20-way multi
screen
VSM-24(A) &
VCM-24(A)
9 9
VSM-28(A) &
VCM-28(A)
9 9 9
VSM-212 & VCM-
212
9 9 9
VSM-216 & VCM-
216
9 9 9
VSM-220 & VCM-
220
9 9 9 9
2.3.1 Full Screen Images
A full screen camera image may be view on Monitor “A” in both “RECORD” and “PLAY” modes.
Press one of the camera select keys (identified as 1, 2, 3, 4 etc) to view the full screen image.
2.3.2 Quad Images (4-Camera multiplexers only)
The VCM-24 and VSM-24 multiplexers allow a full screen or a quad to be displayed on monitor
“A”, and a Quad to be displayed on monitor “B”. Press the “1-4” key and hold for 1 second to
display the quad image on Monitor “A”.
