4. SET Key Options
Whilst the basic configuration is by means of the DIL switches, further facilities are available by
using the SET key in combination with other front panel keys. In all cases the SET key should be
pressed and held, then other keys pressed one at a time as detailed below. Releasing the SET key
finishes the operation.
The 12, 16 and 20 camera multiplexers provide on-screen assistance. When the SET key is pressed
Monitor “A” indicates which other keys should be pressed to access the various SET key functions.
4.1 Auto Sequence Dwell Time (Full Screen)
Press and hold SET, then press “AUTO FULL”. Release when the required time has elapsed.
4.2 Auto Sequence Dwell Time (Quad Screen)
Press and hold SET, then press “AUTO SPLIT”. Release when the required time has elapsed.
4.3 Auto Sequence Camera Selection
Press and hold SET, then press “AUTO FULL”, then press the camera select keys (1, 2, 3, 4 etc.) to
turn ON the lights of the cameras that you wish to be sequenced.
4.4 Auto Sequence Quad Selection
Press and hold SET, then press “AUTO SPLIT”, then press the quad select keys (1-4, 5-8, 9-12
etc.) to turn ON the lights of the quads that you wish to be sequenced.
4.5 Alarm Hold Time
Press and hold SET, then press “CAMERA 1”. Release when the required time has elapsed.
4.6 Alarm Sequence Dwell Time
Press and hold SET, then press “CAMERA 2”. Release when the required time has elapsed.
4.7 Alarm Relay Hold Time
Press and hold SET, then press “CAMERA 3”. Release when the required time has elapsed.
4.8 Covert Cameras
4.8.1 Log In
To view covert cameras or change covert settings you must log in using a PIN number to gain
access, remember to log out when you have finished.
Press and hold SET, then press “VCR VIEW”. While still holding the SET key, enter the correct 4
digit PIN number, using the camera select keys (1, 2, 3, 4 etc.).
Note should you forget the PIN number, you must restore the multiplexer to factory-set defaults, as
described in section 4.12.
4.8.2 Covert Camera Selection
Press and hold SET, then press “VCR VIEW”. While still holding the SET key, press the camera
select keys (1, 2, 3, 4 etc.) as required to turn OFF the lights of camera keys representing cameras
that you wish to be covert.
4.8.3 Change PIN Number
To change your PIN number, press and hold SET, then press “VCR VIEW”, then press “QUAD 1-
4”. While still holding the SET key, enter a 4 digit PIN number, using the camera select keys (1, 2,
3, 4 etc.).
