Model Modes
VQ-402M
VQ-402C
• Full Screen
• Quad,
• PIP (picture in picture)
VQ-403C • Full Screen
• Quad
• PIP
• Dual PIP
• Vertical Split
• Horizontal Split
2.3 Full Screen Selection
To display a full screen image, press camera key 1, 2, 3 or 4.
2.4 Auto-Sequencing
To switch auto-sequencing ON, press and hold a camera key, then momentarily press the key. To
cancel auto-sequencing, press any camera key or select a multi-screen mode.
2.5 Remote Keyboard
The unit may be remotely controlled by any Videoswitch VK-series remote keyboard, or by a computer
running suitable software.
3 Configuration
A number of user preferences may be configured using the SETUP mode. These settings are stored when
power is removed. The factory default settings can be easily restored to provide known starting conditions.
Note that all cameras should be connected when using SETUP mode so that you can see the effects of any
changes made. This unit does not generate on-screen text.
3.1 Restore Factory Defaults
To restore the factory defaults, hold the ALT key on while turning on the power.
Note that the default screen mode is QUAD.
3.2 Set Remote Control Address
The address that the unit uses for control via a remote keyboard is set as follows:
To set the unit address, hold the ALT key and one of the camera select keys (1, 2, 3 or 4) while turning on
the power. The unit address will be set to 1, 2, 3 or 4 respectively.
