Video Processor
3.3 Display
3.3.1 Format
Prior to editing image positions of title positions, select the screen format that you wish to
edit.
3.3.2 Image Positions
• Use
the number keys 1, 2, 3 and 4 to select the camera for which you wish to
adjust the image position.
• Use
the up and down keys to select which field you wish to edit
• Use
the left and right keys to edit the number in the selected fields
• Use
DEFAULT to restore the factory defaults of the selected screen format
• Repeat for other cameras
• Press
ESC to exit this screen back to the menu
The image parameters that can be adjusted are:
Field X range Y range
Comments
Visible YES or NO
Determines whether the camera image is
displayed
Top Left 0 to 176 0 to 142
Position of the top-left corner of the
displayed camera image
Bottom Right 0 to 176 0 to 142
Position of the bottom-right corner of the
displayed camera image
Scale 0 to 255 0 to 255
The scale of the displayed image relative
to the input image (255 represents 1:1)
Offset 0 to 176 0 to 142
The position in the input image that
becomes the top-left of the display
image.
Mirror YES or NO YES or NO
Set to YES if you want the image to be
mirrored horizontally, vertically or both.
Note:
• The coordinate X=0, Y=0 represents the top-left of the image.
• X-coordinates refer to the horizontal, larger numbers being further to the right
• Y-coordinates refer to the vertical, larger numbers being further to the bottom
3.3.3 Title Positions
• Use
the number keys 1, 2, 3 and 4 to select the camera for which you wish to
adjust the image position.
