Videoswitch Vi-Q4C1 - Manual (Page 10)

Video Processor
3.1 Login
Some parts of the menu are password protected. Enter the password here to gain access to
the menu.
• Use
left and right to move the cursor
• Use
up and down to select the digits
• Use
left or ESC to exit this menu item
A message on the screen will indicate if you have logged in successfully. A timer keeps you
logged in while you are pressing keys. After a period if inactivity, you will be logged out. You
may manually log out by changing the password to an invalid value (e.g. all zeros). The
default password is: 111100.
3.2 System
3.2.1 Datetime
3.2.1.1 Enter Datetime
Press SEL to start editing the date and time.
Enter the current date and time using the number keys.
Use the left and right keys to move between the digits as required if you do not want to re-
enter the whole date and time.
The date/time format is DD/MM/YY HH:MM:SS.
Press SEL when you have finished editing the date and time, or press ESC to cancel.
Battery backup ensures that the clock continues working even when power is removed for
short periods of time
3.2.1.2 Daylight Saving
If you select the daylight saving option, the clock automatically moves forwards an hour
during March and back an hour in October for daylight saving. No adjustment by the user is
required when the clocks change. The times and dates suit most European countries.
3.2.1.3 Show Datetime
This option determines whether the dat and time is displayed on the screen.
3.2.2 Vga Mode
This menu item allows the VGA output format to be set to suit the connected VGA monitor.
Choose the resolution to get the best results from the connected VGA monitor.
3.2.3 Language
Select from available languages using this option.
3.2.4 Restore Factory Defaults
If you wish to restore all screen formats and other settings the factory defaults, select Yes in
this menu option.
6
