10 Connections
10.1 Audio
• Connect a microphone either directly to the MIC input or via a microphone amplifier
to the LINE input.
• The LINE output is used to drive either a speaker with a built-in amplifier or a
separate amplifier and speaker.
MICROPHONE
ELECTRET
MICROPHONE
POWER
AMPLIFIER
SPEAKER
OR
HEADPHONES
MICROPHONE
AMPLIFIER
Vi600
