Jibstick layout and functions – VariZoom VZCINEMAPRO-JR-K4 User Manual
Page 6
Analog lens control connector- White
Digital lens control connector- Gray
Set pan axis soft limits
Set tilt axis soft limits
Analog lens voltage balance
Pan/tilt smoothing
Pan speed
Tilt speed
Joystick for pan and tilt operation
Pan/Tilt/Zoom/Focus Response Direction
Communication Connection
USB connector
Sync
Power
Motor Power
After all connections have been made and the camera is balanced, the head is ready to be powered up.
Connect the power supply to AC power. Plug in the green communication connector to the head, and
the other end to the jibstick. The jibstick should now power up. Once the Sync light is illuminated, you
may then turn on the motor power switch.
2. Jibstick layout and functions
USB Connector- This is where you will connect the jibstick to a Windows computer for advanced
parameter settings. A Windows based GUI is provided with the jibstick
Communication connector- Green
