Linear Displacement Transducers (LDT) play an important role in factory automation. They provide

accurate, reliable, absolute position feedback to help automate today’s sophisticated machinery.

Sensors must deliver value, be easy to set up, and interface easily into the host controller.

The 955 eBrik™ Linear Displacement Transducer (LDT) is an ideal alternative to the traditional

low-cost Linear Potentiometer. The advantages of the 955 eBrik over the traditional potentiometer

are that the 955 eBrik™ is an accurate, programmable zero & span, auto-tuning, non-contact

position sensor in an economical low profile package, that uses our field proven Magnetostrictive

technology to give absolute analog feedback.

Potentiometers are electro-mechanical devices that consist of a moveable wiper and resistive

element to provide a voltage feedback. Potentiometers are subject to wear from repetitive

operation and vibration, not to mention that they also drift with temperature. Contaminants are

also a problem as they can enter into the sensors housing and interrupt the contact from the wiper

to the resistive element, causing premature failure or erratic position signals.

With no moving parts and the IP67 rating the 955 eBrik™ is an ideal alternative. The 5 pin connector

simplifies wiring and allows for quick replacement. Programmability allows you to scale the LDT

exactly for your application, or fine tune it in the field. Diagnostics are built into every unit and

are transmitted to the host controller via the analog output. If there is ever a fault, the eBrik™ will

transmit a fault voltage or current warning the host controller that there is a problem.

Typical Industries

• Plastic Injection Molding

• Hydro Power Generation

• Material Handling

• Packaging Machinery

• Pulp & Paper

• Factory Automation

• Sawmill & Woodworking

• Tire & Rubber

• Hydraulic Presses

• Non-contact technology (Magnetostrictive)

• Absolute analog feedback (Voltage or Current) – 16-Bit resolution

• Longevity – Nothing to wear out

• Economically priced

• Programmable Zero & Span points

• Industry standard mating cordset- 5 pin 12mm Micro

• Floating or Slide magnet option for easy integration to the host controller

• Wide operation temperature range with low drift

Benefits

The need for automation is greater today than ever before

955 eBrik™ Linear Displacement Transducer

The 955 eBrik™ is an accurate, programmable zero and span, auto-tuning, non-contact linear position sensor in an
economical, low-profile package. The sensor utilizes our field-proven Magnetostrictive technology to provide absolute
position, repeatable to .001% of the sensing distance.

The 955 eBrik™ is a cost effective linear sensing solution. The streamlined anodized aluminum extrusion houses
the sensing element and electronics. The magnet moves over the sensing element that determines the position and
converts it to a readable output. The 955 eBrik™ is a self-contained unit and does not have a “can” or head assembly.
All of the electronics are incorporated in the transducer, which is less than one inch tall.

Units can be ordered in span lengths up to 72 inches long in 1 inch or 25mm increments. The slide magnet is, designed
to move effortlessly along the transducer in guide tracks, or a floating magnet assembly can be positioned above
the unit. A variety of hardware is available for attaching the magnet slide to the moving portion of the process. The
transducer can be ordered with 0 to 10 VDC or 4 to 20 mA output.

All units are provided with our standard 5 pin 12mm Euro Micro connector, mounting feet and magnet assembly.
Mating cables are sold in various lengths and must be ordered separately.

The 955 eBrik™ has some truly unique features. One feature is the LDT’s auto-tuning capability, the ability to sense the
distance between the magnet and the sensing surface and adjust its signal strength accordingly. As a bonus feature,
the 955 eBrik™ offers programmability, the ability to rescale the zero and span positions or invert the positions in the
field. This is an optional feature and must be called out at time of order under the “Options” field. All units come fully
programmed from the factory, are 100% absolute, and do not require reprogramming unless desired. There is a unique
diagnostic that is built into the analog output on every unit. If there is a loss of magnet, or if the magnet assembly
moves beyond the programmed range, the analog output will transmit a fault voltage or current, warning the host
controller that it is out of range.

The transducer can be mounted vertically or horizontally using our mounting feet which slide on the lower part of the
extrusion and clamp down when tightened. This packaging provides a compact and easy method of mounting for
machine builders.

The 955 eBrik™ is designed for applications where economical continuous feedback is necessary. The sensor can be
a cost effective replacement to linear potentiometers, limit and proximity sensors. Applications include presses, blow
molding, injection molding, extruding, roll positioning, tire press, material handling, web tensioning, sawmill, hydro
power generation and many more.
