background image

Rev. 0040805011 4608

Page 7

Operating and installation instructions

CONA

®

S - Ball float steam traps

8.0 Troubleshooting

In the event of malfunction or faulty operating performance check that the installation and
adjustment work has been carried out and completed in accordance with these Operating
Instructions.

If malfunctions cannot be eliminate with the help of the following table
9.0 Troubleshooting table”, the supplier or manufacturer should be consulted.

9.0 Troubleshooting table

-

ATTENTION !
- It is essential that the safety regulations are observed when identifying faults.

ATTENTION !
- refer to item 10.0 and 11.0 prior
to dismantling and repair work!
- refer to item 6.0 before re
starting the plant!

Fault

Possible cause

Corrective measures

No flow

Installed in wrong flow direction

Fit valve in direction of flow arrow.
Note installation position
Check lifting force; refer to item 5.5!

Ball float defective

Replace steam trap

Controller operated above safe operating
pressure

Observe operating limits as per data
sheet, i.e. possibly select different
controller

Reduced flow

Wrong installation position

Note installation position; refer to item
5.5. Correct installation position.

Piping system clogged

Check piping system

Wrong controller size choosen

Correct selection acc. to flow diagram

No closure, or internal
leakage

Controller clogged

Clean controller; refer to item 7.1

Controller worn out

Replace steam trap

External leakage

Body not properly tightened

Replace steam trap
