Page 5

Rev. 0040401000 2913
Page 2-5
Operating and installation instructions
SAFE, SAFE-P, SAFE-TC, SAFE-TCP/TCS
4.3.1 Parts list
Refer to the data sheet for information about materials.
Pos.
Description
Pos.
Description
1
Body
32
Hex. nut
2
Seat (not changeable)
33
Lift bolt
2
Screwed seat (SAFE-TC)
34
Screw
3
Stud
35
Lift fork
4
Spindle guide
36
Lifting lever
7
Gasket
37
Spring
8
Hex. nut
38
Screw
9
Lift limitation ring
39
Bolt
10
Spindle ring
40
Split pin
11
Bonnet, closed
41
Lever open
12
Disc unit
42
Bonnet, open
13
Lifting aid
43
Bellow
14
Spindle
44
Ring
15
Gasket
45
Ring
16
Spring type straight pin
47
Ball
17
Adjusting screw
48
Retaining ring
18
Ball
55
Bellow unit
19
Spindle cap
59
Protective rim
20
Parallel pin
60
Spacer
21
Lock nut
61
Coupling
22
Hex. head screw
62
Weight
23
Lead seal
63
Guide bush
25
Snap ring
65
Coupling
26
Spring plate
66
O-Ring
27
Gasket
67
Lift button
28
Cap, closed
68
Spring type straight pin
29
Cap open
70
Balanced piston
31
Ring
