Setting Up - NetWare
48 AXIS 540+/AXIS 560
1. Click Manually specify the print server and enter the
Network Number> in the Network field.
2. Enter the in the LAN HW address field and
choose a port in the Print Server Port field:
e.g.: 01d7e1c2:00408c5ff6a6 and LPT1.
The port numbers are LPT1, LPT2 or COM1.
3. When done, select your printer and click Finish.
4. Next, select the printer drivers for each client operating system. (Windows
2000, Windows NT4 and Windows 95/98). These drivers will be automatically
downloaded to users’ workstations when they install this printer in the future.
Ports available Parallel port 1 Parallel port 2 Serial port
AXIS 540+ LPT1 — —
AXIS 560 LPT1 LPT2 COM1
