User Guide
P. 3
• Pressing and holding the
UNLOCK
button for more than 3 seconds will unlock all doors and will
send a constant pulse as long as the
UNLOCK
button is held down (maximum of 15 seconds).
This constant pulse can be configured to activate certain functionalities such as rolling down the
windows – Please refer to your installer to see if your vehicle is compatible with this
option.
Feature Confirmation Chart
Feature
LED #1
LED #2
LED #3
LED #4
Beep(s)
Lock 3
flashes X
X
X
1
Unlock X 3
flashes X
X
2
Trunk X X
3
flashes
X 1
Start X X X
3
flashes
1
Start out of ready
mode
X X X
3
flashes
4
Running X X X
3
flashes
3
Stop X X X
3
flashes
2
Entering Cold
Weather Mode
X
X
X
3 flashes
1...+ ... 2
Exiting Cold
Weather Mode
X
X
X
3 flashes
1... + ...1
Home Valet
3 flashes
X
X
3 flashes
2
Valet Mode
3 flashes
X
X
3 flashes
1
Exit Valet Mode
X
3 flashes
X
3 flashes
1
Vehicle Status Request
The status request feature allows the user to see the status of the vehicle
i.e.: if the doors are
locked or unlocked or if the vehicle is in cold weather mode, home valet mode, in valet mode or
how much time is left in the run time cycle. The following charts (Tables 1, 2 and 3) indicate the
confirmation sequences.
To retrieve the vehicle status:
Press and release the
SHIFT
button then press and release the
TRUNK
button (there will be a beep).
The transmitter will then flash the corresponding sequence of LEDs depending on the vehicle’s
status.
x
If the engine is NOT running, refer to Table 1.
x
If the engine IS running under a remote start, refer to Table 2 (if the doors are locked)
or refer to Table 3 (if the doors are unlocked).
The status request feature is a two-step procedure:
• The first sequence of flashes denotes if the vehicle’s doors are locked or unlocked.
• The second sequence of flashes (if applicable) denotes if the vehicle is Cold weather mode,
Home valet mode, or, Valet mode or out of Ready Mode.
• If there is no second sequence transmission, that the vehicle is not in any of the three (3)
mentioned features (Cold weather mode, Home valet mode or Valet mode or out of Ready
Mode).
