User Guide P. 17
Diagnostics – Parking Light Flash Table
Flashes Description
1
• Doors locked, Alarm and starter kill armed.
• Run time has expired.
• TRUNK button pressed.
• Start signal received by the module.
• Cold weather mode cancelled.
2
• Remote start attempt cancelled by remote.
• Doors unlocked, starter kill disarmed.
• Exiting ignition valet
• Exiting remote valet
• Power-up reset.
3
• Entering cold weather mode
• Entering ignition valet
• Entering or exiting Ready Mode
• Entering remote valet.
• Entering extended run time.
3 slow flashes… …after a failed start attempt The module did not detect a tach signal.
4
• +12 V detected on the brake input wire either while cranking or during run time.
• Entering multi-speed tach programming.
5 Slow • Start attempt failed because no tach signal has been programmed.
5 Fast
• Tach signal programmed.
• New transmitter programmed.
6 • A remote start was attempted while a tach-before-crank signal was detected before cranking.
8 • Unit reset
10 • A ground (-) signal was detected on the hood pin input wire.
1 – pause – 2
• There was a remote start attempt while the vehicle was in valet mode.
• Failed start: vehicle’s low battery voltage.
2 – pause – 2 • There was an attempt to start the vehicle while the module was in valet mode.
…followed by 1 flash Exiting cold weather mode ON SOLID for 3
seconds….
…followed by 3 flashes Entering cold weather mode
ON continuously • Idle mode: Idle mode is engaged
• Run time: The vehicle has been remote started and is in run time.
ON continuously While the brake pedal is pressed.
•
Confirms that cold weather mode is engaged
ON 2 seconds
• The hood has been opened and a ground (-) signal has been detected on the hood pin input
wire.
ON 4 seconds • Locking or unlocking a door (with Door pulses configured to 4 sec.)
ON 20 seconds • The hood pin has been flashed and you now have access to the programming options.
ON 25 SEC.
• The Hood Pin-switch has been pressed twice: the Unit went into step 1 of the Programming
Centre procedure, and no Transmitter activity was detected for 20 seconds.
• Or the Unit went into step 1 of the Transmitter Programming procedure and no activity was
detected for a few seconds. The Unit has exited the Transmitter Programming procedure.
• Panic Mode is activated.
CONSTANT FLASHES
UP TO 60 SEC.
• In Siren or Horn Mode: Alarm condition generated by an intrusion, or when the System is
powered up.
