Tighten the 3 screws. Use of electric powered screwdrivers is not recommended.
HOW TO SHORTEN THE DRIVE SHAFT
Bondioli & Pavesi advises against altering its products. If modifications are required,
we recommend that you consult your implement dealer or a qualified service center
before proceeding. If the driveline is too long adopt the following procedure.
Remove the shielding.
Shorten the drive tubes by the required length.
Telescoping tubes must always overlap by at least 1/2 of their length in
normal operation and at least 1/3 of their length in all working conditions.
During maneuvers, when the driveline is not rotating, the telescoping tubes must
have a suitable overlap to maintain the tubes aligned and allow them to slide freely.
Carefully deburr the ends of the tubes with a file and remove all filings from
the tubes.
Shorten shield tubes one at time by cutting the same length that was cut
from the drive tubes.
Grease the internal drive tube and reassemble the shielding on the driveshaft.
Check the length of the driveshaft at its minimum and maximum extensions
on the implement.
TROUBLESHOOTING
WEAR OF YOKE EARS
EXCESSIVE WORKING ANGLE
• Reduce the working angle.
• Disengage PTO when joint angle exceeds 45°.
DEFORMATION OF YOKES
EXCESSIVE TORQUE PEAK OR SHOCK LOAD
• Avoid overloading or engaging PTO when under load.
• Check the efficiency of the torque limiter.
CROSS ARM BROKEN
EXCESSIVE TORQUE PEAK OR SHOCK LOAD
• Avoid overloading or engaging PTO when under load.
• Check function of torque limiter.
ACCELERATED WEAR OF CROSS ARMS
EXCESSIVE LOAD
• Do not exceed the speed or power limits indicated in the instruction manual.
INSUFFICIENT LUBRICATION
• Follow instructions in point 37.
SEPARATION OF TELESCOPING TUBES
EXCESSIVE EXTENSION OF DRIVELINE
• Do not extend driveline to the point that the tubes separate.
• For stationary machinery, position the tractor so the telescoping tubes overlap
as illustrated in point 10.
