HMP140A SERIES
U175en-1.5 Appendix 2
1999-12-08 1
APPENDIX 2: SETTINGS OF THE LOCAL DISPLAY
RH/T
°C
°F
Figure 1 Location of the RH/T button and the
°
C/
°
F jumpers
The reading on the local display (relative humidity or temperature) can be
chosen by pressing the RH/T button beside the display. At power-up, the
display always shows the relative humidity reading. This can be changed to
temperature reading by pressing the RH/T button once. Further pressings will
change the reading between RH and T.
The temperature unit (
°
Celsius or
°
Fahrenheit) is chosen with the jumper on
back of the local display unit. For
°
C, the jumper is connected to the lower
position and for
°
F, it is connected to the upper position (see Figure 1).
NOTE!
The HMP140A series transmitters with the local
display and current output cannot be re-scaled.
