Figure 3, Electrical connections – Vaisala HMM211 User Manual
Page 19
Chapter 4 _______________________________________________________________ Installation
3
1
2
Figure 3
Electrical Connections
The following numbers refer to Figure 3 above:
1 = During normal use, leave the jumper as indicated here (factory
setting).
2 = Calibration connector for the HM70 or HMI41
3 = Calibration jumper when not in use
VAISALA _______________________________________________________________________ 19
