Page 13
12
Measurement Views
Screen Layout and Controls
Battery
indicator
Alert indicator
Change quantity
Enter menu
Long press:
tag point
Short press:
tag point and
hold screen
Measurement
display area
Long press: power on/of
Short press: activate backlight
Current quantity
Change
view
Current
view
Pressing the right function button holds the screen
and tags the current measurement point.
See Hold and Tag on page 18.
