MULTITASKER™
400-0197-005 22
22
4 x 4
I
NPUTS
O
UTPUTS
1
a
1
a
1 b 1 b
2 a 2 a
2 b 2 b
3
a
3
a
3
b
3
b
4 a 4 a
4 b 4 b
2 x 2
I NPUTS O UTPUTS
1 a 1 a
1 b 1 b
1
c
1
c
1 d 1 d
2 a 2 a
2 b 2 b
2 c 2 c
2
d
2
d
46. [HELP]
This command displays information available for
the MultiTasker™ interface commands.
Command Format: [HELPCnUi]
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example:
In order to display the RS-232 commands
available for the MT110-103 card in slot 2, send
the command [HELPC2]. The commands along
with a brief description will be displayed in the
terminal window.
7.3. SUMMARY OF COMMANDS
Card Commands
1) [VER] Receives software version
2) [C] Receives status of the card
3) [CnS] Save card settings
4) [?] Show system cards
5) [?C] Show card information
6) [STA1] Enable auto feedback
7) [STA0] Disable auto feedback
8) [ON] Turns on one or more outputs
9) [OFF] Turns off one or more outputs
10) […S] Save the command being sent
11) […F] Show command feedback
12) […P] Sets the path, preload for [SW]
13) [SW] Switch preloaded output buffer
14) [IO] Connect an input to output
15) [IO*] Connect an input to all outputs
16) [CLR] Reset card to default values
17) [OSI] Set input offset
18) [OSO] Set output offset
19) [FBD] Feedback delay on/off
ID Commands
20) [RSI] Reset Card IDs
21) [SIDn] Set all Card IDs
22) [SIDnCi] Set one Card ID
23) [SID+] Set Card ID offset
24) [RSN] Read Card slot number
Group Commands
25) [WR] Groups multiple cards
26) [RMC] Remove members from group
27) [RMG] Delete group
28) [RD] Displays group members
Volume/Matrix Commands
29) [TEST] Test internal memory ICs
30) [VLO] Set absolute output volume
31) [SEL] Select input volume to adjust
