Multitasker – Altinex MT110-101 User Manual
Page 2
MULTITASKER™
400-0197-005
1
1
TABLE OF CONTENTS
Page
PRECAUTIONS / SAFETY WARNINGS ............... 2
GENERAL..........................................................2
INSTALLATION .................................................2
CLEANING.........................................................2
FCC / CE NOTICE..............................................2
ABOUT YOUR MT110-101/103............................... 3
TECHNICAL SPECIFICATIONS ............................ 3
DESCRIPTION OF MT110-101/103 ....................... 4
APPLICATION DIAGRAM ........................................ 5
D
IAGRAM
1: T
YPICAL
S
ETUP
.................................5
D
IAGRAM
2: MT110-103 I
NTERNAL
V
IEW
..............6
D
IAGRAM
3: MT110-101 I
NTERNAL
V
IEW
..............7
INSTALLING YOUR MT110-101/103 ..................... 8
OPERATION ............................................................... 8
RS-232 CONTROL.............................................8
DESCRIPTION OF COMMANDS .......................8
SUMMARY OF COMMANDS ...........................22
TROUBLESHOOTING GUIDE .............................. 23
LED IS NOT LIT ...............................................23
LED IS BLINKING RED ....................................23
NO SOUND......................................................24
DISTORTED SOUND.......................................24
SOUND LEVEL IS LOW ...................................24
ALTINEX POLICY .................................................... 25
LIMITED WARRANTY/RETURN POLICY ........25
CONTACT INFORMATION ..............................25
