State Tilt Roof User Manual
Page 2
2
“B”
“A”
TILT ANGLE
4” MOUNTING STRUT
(see Figure 4.)
4” C-CHANNEL
(see Figure 3.)
COLLECTOR
MOUNTING
STRUT
6 PLACES PER COLLECTOR
STAINLESS STEEL BOLT,
FLAT WASHER, LOCK WASHER,
& NUT (see Figures 3-5.)
C-CHANNEL
TILT RISER
UPPER COLLECTOR
LOWER COLLECTOR
“C”
Figure 1.
Figure 2.
Figure 5.
BOLT
NUT
LOCK
WASHER
FLAT
WASHER
MOUNTING BRACKET LOCATIONS
D”
E”
E”
A”
D”
Figure 3.
Figure 4.
&2//(&725
7,/7 $1*/(
“A”
MOUNTING
%5$&.(7
SPACING
“B”
/(1*7+
“C”
/(1*7+
“D”
/(1*7+
³(´
/(1*7+
Vert 3.5’ X 7’
15°
91.00
25.25
92.00
32
14
30°
84.00
47.50
45°
73.00
66.50
60°
49.50
80.00
75°
43.50
92.00
Vert 4’ X 8’
15°
95.75
25.25
103.00
35
16
30°
87.50
47.50
45°
77.25
73.50
60°
70.00
92.00
75°
49.50
103.00
Vert 4’ X 10’
15°
119.25
33.50
127.00
30°
106.00
64.00
45°
92.75
90.25
60°
65.00
110.00
75°
61.50
127.00
Table 1.
All Dimensions in Inches
