REPAIR PARTS
3/4” T&P RELIEF VALVE
AUTOMATIC, SELF-CLOSING TYPES
12
A
DRAIN PAN 16
Key No. Part Description
1 Pipe Nipple
2 Burner Tube
3 Burner Head
4 Thermocouple
5 Pilot
6 Draft Hood
7 Inlet Tube
8 Flue Baffl e Assembly
9 Anode Rod
10 Outer Door
11 Gas Control Valve/Thermostat
12 T & P Relief Valve
13 Drain Valve
14 Pilot Tube
15 Orifi ces
16 Metal Drain Pan
*17 Instruction Manual
* Not Shown.
Now that you have purchased this water heater, should a need
ever exist for repair parts or service, simply contact the company
it was purchased from or direct from the manufacturer listed on
the rating plate on the water heater.
Be sure to provide all pertinent facts when you call or visit.
Selling prices will be furnished on request or parts will
be shipped at prevailing prices and you will be billed
accordingly.
The model number of your Gas Water Heater will be found on the
rating place located above the gas control valve.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE
FOLLOWING INFORMATION:
• MODEL NUMBER
• TYPE GAS (NATURAL)
• SERIAL
NUMBER
• PART DESCRIPTION
THIS IS A REPAIR PARTS LIST, NOT A PACKING LIST.
3 4 14 2 5
15
7 8
9
10
11
13
12
PRESS A=
TEMP
RELIEF
150 LBS. 2.13” 210°F
