PURGING

Gas line purging is required with new piping or systems in which air has
entered.

CAUTION

PURGING SHOULD BE PERFORMED BY PERSONS EXPERIENCED
IN THIS TYPE GAS SERVICE. TO AVOID RISK OF FIRE OR
EXPLOSION, PURGE DISCHARGE MUST NOT ENTER CONFINED
AREAS OR SPACES WHERE IGNITION CAN OCCUR. THE AREA
MUST BE WELL VENTILATED AND ALL SOURCES OF IGNITION MUST
BE INACTIVATED OR REMOVED.

GAS METER SIZE — NATURAL GASES ONLY

Be sure the gas meter has suffi cient capacity to supply the full rated gas
input of the water heater as well as the requirements of all other gas fi red
equipment supplied by the meter. If gas meter is too small, ask the gas
company to install a larger meter having adequate capacity.

GAS PRESSURE REGULATOR

The gas pressure regulator is built into the gas valve and is equipped to
operate on the gas specifi ed on model and rating plate. The regulator is
factory adjusted to deliver gas to burner at correct water column pressure
allowing for a nominal pressure drop through the controls.

The minimum gas supply pressure for input adjustment must not be less
than 6" w.c. (1.49 kPa) for natural gas.

Do not subject the combination gas valve to inlet gas pressures of more
than 14.0" w.c. (3.48 kPa) - natural gas. A service regulator is necessary
if higher gas pressures are encountered.

Gas pressure specifi ed in Table 5, refer to fl ow pressure taken at pressure
tap of automatic gas valve while heater is operating.

TABLE 6. GAS PRESSURE

Type of

Gas

Input

Manifold Pressure

Natural

75,100 Btu/hr

22 KW/hr

4.0 in. W.C.

1.12 kPa

OPERATION

It is recommended that a qualifi ed person perform the initial fi ring of the
heater. At this time the user should not hesitate to ask the individual any
questions which he may have in regard to the operation and maintenance
of the unit.

TO OPERATE THE HEATER

1. Close the heater drain valve (Figure 1) by turning handle clockwise

.

2. Open a nearby hot water faucet to permit the air in the system to

escape.

3. Fully open the cold water inlet pipe valve (Figure 1) allowing the heater

and piping to be fi lled.

4. Close the hot water faucet as water starts to fl ow.

5. The heater is ready to be operated.

WARNING

DO NOT ATTEMPT TO OPERATE WATER HEATER WITH COLD
WATER INLET VALVE CLOSED.

NEVER OPERATE THE HEATER WITHOUT FIRST BEING CERTAIN IT IS
FILLED WITH WATER AND A TEMPERATURE AND PRESSURE RELIEF
VALVE IS INSTALLED IN THE RELIEF VALVE OPENING OF THE HEATER.

TABLE 5 MAXIMUM CAPACITY OF PIPE IN

CUBIC FEET PER HOUR

BEFORE PLACING THE HEATER IN OPERATION, CHECK FOR GAS
LEAKAGE.

Use soap and water solution or other material acceptable for

the purpose in locating the leaks.

DO NOT USE MATCHES, CANDLES,

FLAME OR OTHER SOURCES OF IGNITION FOR THIS PURPOSE.

FIGURE 5. GAS PIPING AND SEDIMENT TRAP INSTALLATION

DISCONNECT THE HEATER AND ITS MANUAL GAS SHUTOFF VALVE
FROM THE GAS SUPPLY PIPING SYSTEM DURING ANY SUPPLY
PRESSURE TESTING EXCEEDING 1/2 PSIG (3.45 kPa). GAS SUPPLY
LINE MUST BE CAPPED WHEN DISCONNECTED FROM THE HEATER
FOR TEST PRESSURES OF 1/2 PSIG (3.45 kPa) OR LESS. THE WATER
HEATER NEED NOT BE DISCONNECTED, BUT MUST BE ISOLATED
FROM THE SUPPLY PRESSURE TEST BY CLOSING THE MANUAL GAS
SHUTOFF VALVE.

LENGTH

IN

FEET

NORMAL IRON PIPE SIZES (INCHES)

INPUT IN THOUSANDS BTU/HR

1/2"

3/4"

1"

1 1/4"

1 1/2"

2"

2 1/2"

3"

4"

10

175

360

680

1400

2100

3960

6300

11000

230000

20

120

250

485

950

1460

2750

4360

7700

15800

30

97

200

375

770

1180

2200

3520

6250

12800

40

82

170

320

660

990

1900

3000

5300

10900

50

73

151

285

580

900

1680

2650

4750

9700

60

66

138

260

530

810

1520

2400

4300

8800

70

61

125

240

490

750

1400

2250

3900

8100

80

57

118

220

460

690

1300

2050

3700

7500

90

53

110

205

430

650

1220

1950

3450

7200

100

50

103

195

400

620

1150

1850

3250

6700

125

44

93

175

360

550

1020

1650

2950

6000

150

40

84

160

325

500

950

1500

2650

5500

175

37

77

145

300

460

850

1370

2450

5000

200

35

72

135

280

430

800

1280

2280

4600

LENGTH

IN

METERS

NORMAL IRON PIPE SIZES (INCHES)

INPUT IN KW

1/2"

3/4"

1"

1 1/4"

1 1/2"

2"

2 1/2"

3"

4"

3.0

51

105

199

410

615

1160

1845

3221

6735

6.1

35

73

142

278

428

805

1277

2255

4626

9.1

28

59

110

225

346

644

1031

1830

3748

12.2

24

50

94

193

290

556

878

1552

3192

15.2

21

44

83

170

264

492

776

1391

2840

18.3

19

40

76

155

237

445

703

1259

2577

21.3

18

37

70

143

220

410

659

1142

2372

24.4

17

35

64

165

202

381

600

1083

2196

27.4

16

32

60

126

190

357

571

1010

2108

30.5

15

30

57

117

182

337

542

952

1962

38.1

13

27

51

105

161

299

483

864

1757

45.7

12

25

47

95

146

278

439

776

1610

53.3

11

23

42

88

135

249

401

717

1464

61.0

10

21

40

82

126

234

375

688

1347
