3” BULL BAR
2011-13 F-150 WITH ECOBOOST
Page 2 of 3 7/1/13 Rev1 (DP)
results. Once properly trimmed to clear the Brackets, reinstall the cover. Reinstall the Bull Bar
as described in Steps 3 & 4.
5. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, wax this product after installing. Regular waxing is recommended to add a
protective layer over the finish. Do not use any type of polish or wax that may contain abrasives that could
damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild
soap may be used also to clean the Bull Bar.
For gloss black finishes: Mild soap may be used to clean the Bull Bar.
Driver Side Installation Pictured
Use the factory tow hook
hardware or the included:
(2) 12mm x 40mm Bolt Plates
(2) 12mm Flat Washers
(2) 12mm Lock Washers
(2) 12mm Hex Nuts
Fig 2
Fig 1
Remove tow hooks if equipped
Insert Bolt Plates
through opening in
end of frame channel
NOTE: On vehicles without tow hooks, the
area circled above may be covered, (see
Figure 4). Remove the lower plastic bumper
cover to access the front of the frame
channel for Bracket installation
