Dee Zee DZ500747 - Manual (Page 4)

3" BULL BAR
99-06, 07 "CLASSIC" CHEVY SILVERADO1500/GMC SIERRA1500
02-06 AVALANCHE 1500, 00-06 SUBURBAN 1500, 00-06 TAHOE1500/YUKON 1500
Page 3 of 3 2/27/12Rev1(DP)
Driver Side Installation Pictured
(2) 12mm Flat Washers
(2) 12mm Lock Washers
(2) 12mm Hex Nut
(2) 10mm x 35mm Hex Bolts
(4) 10mm Flat Washers
(2) 10mm Lock Washers
(2) 10mm Hex Nuts
(Fig 8) Driver/Left side installation illustrated
12mm Bolt Plate
12mm Flat Washer
12mm x 40mm Hex Bolt
12mm Flat Washer
Front
Fig 7 (2) 10mm x 35mm Hex Bolts
(4) 10mm Flat Washers
(2) 10mm Lock Washers
(2) 10mm Hex Nuts Complete Installation
Bull Bar
Tow Hook
Frame Channel
