Dee Zee DZ500747 User Manual

Page 3

3" BULL BAR

99-06, 07 "CLASSIC" CHEVY SILVERADO1500/GMC SIERRA1500

02-06 AVALANCHE 1500, 00-06 SUBURBAN 1500, 00-06 TAHOE1500/YUKON 1500

Page 2 of 3

2/27/12Rev1(DP)

Driver Side Installation Pictured

Fig 1

(Fig 2) Dotted line pictured for example only

Fig 3

Fig 4

Fig 5

Fig 6

12mm Bolt Plate
12mm Flat Washer
12mm Plastic Retainer

12mm x 40mm Hex Bolt
12mm Flat Washer

(2) 12mm Flat Washers
(2) 12mm Lock Washers
(2) 12mm Hex Nut

Front
