Dee Zee DZ500825 - Manual (Page 4)

GRILLE GUARD
07-12 TOYOTA FJ CRUISER
Page 3 of 4 4/30/12 Rev 1 (DP)
Driver Side Installation Pictured
Fig 3
Driver side Frame Bracket
(Fig 5C) Driver side Top Support
Bracket installation pictured without
grille
Driver side Top
Support Bracket
(2) 6mm x 25mm Hex Bolts
(2) 6mm Flat Washers
(2) 6mm Lock Washers
Front
Front
(2) 10mm x 120mm Hex Bolts
(2) 10mm Large Flat Washers
Driver side Top
Support Bracket
Driver side Top
Support Bracket
Fig 4B
Fig 4A
Fig 5A
(2) 6mm x 25mm Hex Bolts
(2) 6mm Flat Washers
(2) 6mm Lock Washers
Fig 5B
Front
Front
Front
Front
