PLATE
DZ 16201
DZ 16202
DZ 16203
X2 PN 835 X6 PN 714 X6
BRACKET BRACKET BRACKET BRACKET
B 1749LP X1 B 1749RP X1 B 1750LP X2 B 1750RP X2
PN 525 X6 PN 527 X6 PN 524 X12 PN 526 X12
PN 556 X1 PN 72B X1
8mm X 25mm BOLT
6mm x 20mm BOLT
DZ 16260 DZ 16260 DZ 16260 DZ 16260
TOYOTA HIGHLANDER TOYOTA HIGHLANDER TOYOTA HIGHLANDER TOYOTA HIGHLANDER
LARGE THREADED SMALL THREADED
A B C
PLATE
RIGHT MIDDLE/REAR
J
8mm X 20mm BOLT
E F G
I
8mm NUT
K
RIGHT FRONT LEFT MIDDLE/REAR
8mm SQUARE
WASHER
*SOLD SEPARATELY FROM THIS KIT*
H
L M
LEFT FRONT
D
HEAD BOLT
DZ 16260 1 OF 13 1/30/2014
