Dee Zee DZ16241 User Manual
Page 9

Insert the large threaded plate that was installed on the driver's side rear brace [F] into the
slot on the underside of the vehicle just behind the pinch weld.
This picture is from the ground
looking up at the rear mounting
location.
The picture shown is a Durango.
On the Jeep Cherokee, the Durango
hole is not there.
7
CHEROKEE
DURANGO
View
from
front of
vehicle
looking
towards
the rear
mounting
location.
FOR THE CHEROKEE,
THE BOLT WILL BE
HERE
DZ 16241
7 OF 9
2/22/2012
