Page 6
M-M
FOLD 3
DUS
TCAT HE
C
R
10
8. Tension Adjust
Please keep the arm level during tension adjustment. Use a proper Allen key, slightly loosen or tighten the
adjustment screw according to the display weight.
If display settles on its own, then rotate adjustment screw towards the "+" symbol.
If display rises on its own, then rotate adjustment screw towards the "-" symbol.
9. Cable Management
Adjust to the desired location or tilt.
10. Adjustment
Tighten screw till the display angle can be fixed.
9
M-N
Connect the cables to the display, and press cable cover
inward to route the cables through the space.
Note: Leave slack in cable for cantilever arm movement.
h
e
ig
h
t
a
d
ju
s
ta
b
le
m
a
x
3
3
5
m
m
+15°
-15°
180°
180°
+3° -3°
180°
