Warning – Monoprice 9745 Wall Mount Bracket User Manual
Page 4
6
5
4. Install Decorative Covers
5. Assemble VESA Adaptors
X
X
√
• When installing wall mounts on cinder block, verify the actual concrete thickness is at least
1-3/8" (35mm) for using the concrete anchors. Do not drill into mortar joints! Be sure to
mount in a
solid part of the block, generally 1" (25mm) minimum from the side of the block.
It is suggested electric drill on slow setting is used to drill the hole instead of a hammer drill
to avoid breaking out the back of the hole when entering a void or cavity.
• Installer must verify that the supporting surface will safely support the combined load of the
equipment and all attached hardware and components.
WARNING
3b. Mount on Solid Brick and Concrete Block
Drill pilot holes
1
2
Screw the wall
mount onto
the wall
60mm
(2.4")
60mm
2.4"
(
)
60mm
(2.4")
ø 10mm
(ø 3/8")
W-B
W-A
5a VESA 300x300, 400X400
Unit: mm
300
400
0
30
4
0
0
B
5b VESA 400x200
Unit: mm
4 0
0
20
0
