Monoprice 9745 Wall Mount Bracket User Manual
Page 5
8
7
7. Hook the TV onto the Wall Mount
·
Level the TV.
·
Place the lower flat nut and tighten both nuts.
Loosen the upper flat nut spacing
4mm to VESA plate.
4mm
or
TV
TV
TV
6. Install VESA Plate
6-1 For Flat Back Screen
TV
TV
TV
6-2 For Recessed Back Screen
Screw the VESA plate onto the TV.
M-A/M-C
M-E/M-G
M-I/M-J
Tighten all screws but do not over
tighten.
M-B/M-D/M-F
M-I/M-J
M-K
M-H
M-J
M-L
Hook the TV onto the wall mount
