6 5
Insert the sensor base ( with attached TV hook and the XBOX360 KINECT sensor) onto the TV mount platform
until the TV hook catches onto the front of the TV. fig. 3.2
fig. 2.1
Tighten TV Hook Screw
as
shown in fig.2.1
Tighten the TV hook screw to lock the TV hook position into place so that it no longer slides back and forth
.
2
Installing XBOX360 KINECT Sensor
• Take the sensor base (with attached TV hook)and line it up with the base of the
• Press in both grips on the sensor base and fit the sensor base onto the bottom of the
. Release the grips of the sensor base to lock the two together as shown in fig. . .
XBOX360 KINECT Sensor.
XBOX360 KINECT
Sensor 3 1
3
XBOX360 KINECT Sensor
. is not included
Note: the sensor base
switch is pointed at the
back.
loosen
tighten
TV hook
sensor base
fig. 3.1
