NOTE: Please read Instruction Manual prior to installation.
WARNING
•
.
• Tighten screws firmly, but do not over tighten. Over tightening can damage the items,
greatly reducing their holding power.
•
•
• The TV mount for XBOX 360 KINECT Sensor is NOT recommended for wall mounted
TV.
Do not begin installation until you have read and understood the instructions and
warnings contained in this manual. If you need further assistance, please contact
your local distributor
This product is for indoor use only. (Use of this product outdoors could lead to product
failure and personal injury).
Please do not add additional weight to TV mount.
2 1
Component Checklist
Please ensure you have received all parts listed on the component checklist prior to installing. If any parts are
missing or faulty, contact your local distributor for replacement.
Package M
Tools required
Phillips Head Screw driver(200mm length exclude the handle)
extension legs
B
(x2) TV mount platform
A
(x1)
M4x20
M-B
(x2) M4x10
M-A
(x2) M5x10 (x2)
M-C
M5x20 (x2)
M-D
M6x10 (x2)
M-E
M6x20 (x2)
M-F
M8x10 (x2)
M-G
M8x20
M-H
(x2) washer
M-I
(x2)
sensor base (
(x1)
with
attached TV hook)
C
