WARNING
•
• Please refer to manufacture’s installation guide for recommended distance from wall
to avoid risk of property damage.
•
• Make sure that the supporting surface will safely support the combined load of the
equipment and all attached hardware and components.
• Never exceed the maximum load capacity.
• If mounting to wood wall studs, make sure that mounting screws are anchored into
the center of the studs. Use of an “edge to edge” stud finder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position
equipment.
• Tighten screws firmly, but do not over tighten. Over tightening can damage the items,
greatly reducing their holding power.
• This product intended for indoor use only. Using this product outdoors could lead to
product failure and personal injury.
Do not begin installation until you have read and understood the instructions and
warnings contained in this manual. If you need further assistance, please contact
Monoprice Technical support team.
This product should only be installed by someone of good mechanical aptitude and
basic building experience to avoid malfunction.
2 1
NOTE: Please read Instruction Manual prior to installation.
Package M
Package W
ST6.3x55 (x6)
W-A
concrete anchor (x6)
W-B
washer(ø6.5xø24) (x6)
W-C
Tools required
Phillips Head Screw driver(200mm length exclude the handle)
M6 Socket and Wrench
Electric drill and 10mm masonry bit for concrete wall installation
Marking Pen
Hammer ·
·
·
·
·
M4x14 (x4)
M-A
M5x14 (x4)
M-B
M6x14 (x4)
M-C
allen key 4mm (x1)
M-J
M8x14 (x4)
M-D
ø13.5xø5.5x3.2 (x4)
M-I
D4 washer (x4)
M-E
D5 washer (x4)
M-F
D6 washer (x4)
M-G
D8 washer (x4)
M-H
