11-APR-06 Rev E OMACS3000
21 of 51 System Screens
Figure 12: Visible Satellites Computed Screen
Figure 13: Satellite Table Downloaded to PC Popup Window
Verify Jog Direction
Before starting this step in the initialization process, the operator MUST place an observer near the antenna
who can be in constant communication with the antenna controller operator. The observer should be able to
see in which direction the antenna moves and whether any wires or wire harnesses that cross the elevation
and azimuth axes become entangled as the antenna moves.
WARNING
Doing this step incompletely or inaccurately may result in
damage to the hardware during later steps or normal
operation.
