BBK Performance 1508 User Manual
Bbk phenolic spacer kits, Special tools required, Install time

BBK Phenolic Spacer Kits
Part # 1506,1508,1520,1530,1549
1
INS-003
Follow these instructions carefully to ensure correct fitment and operation.
Special Tools
Required:
• No special tools
required
Install Time:
Approximately
1 Hour
Difficulty:
3 out of 5
STEP 1
STEP 6
•
Disconnect the throttle duct hose from the
throttle body.
STEP 3
STEP 2
•
Disconnect the wire connectors from the upper
manifold and also the vacuum lines on the
underside of the upper intake.
•
Disconnect the throttle linkage from the throttle
body and also the kick-down linkage if
applicable.
•
Next install the phenolic spacer by placing a
new gasket on both sides of the spacer.
STEP 4
STEP 7
•
Remove the cover plate from the upper intake if
equipped. Next remove the six bolts from the
upper intake manifold.
STEP 5
STEP 8
•
Lift off the upper intake and discard the gasket,
also making sure both surfaces are free from
dirt and grease.
•
Next simply reverse the previous steps.
•
Use the new bolts provided and tighten in a
criss-cross pattern beginning with the center
bolts.
