Wire colors
THREE 380 V + N + T
Black - black - brown ...….... Phases
Blue ..................................... Neutral
Green / yellow ..................... Earth
THREE 220 V + T
Black - brown - blue ........... Phases
Green / yellow..................... Earth
Important:
Install an additional upstream fuse cabinet.
Furthermore, install a residual current operated circuit breaker (300 ma) for the
general protection of your launderette against electrical faults.
These installations must be in accordance with valid regulations.
Note: Fuses protect the control and power circuitry.
Table: motor power
---------------------------------------------------------------------------------------------------------------------------
UHM027D UHM033D UHM049D UHM067D
--------------------------------------------------------------------------------------------------------
Power in kW 4
4 5.5 5.5
--------------------------------------------------------------------------------------------------------
Nominal velocity in tr/min 1500 1500 1500 1500
---------------------------------------------------------------------------------------------------------------------------
Electrical heating:
Machines that have electrical heating have connections for:
• The control and motor circuits.
• The heating power circuit.
Table: heating power
---------------------------------------------------------------------------------------------------------------------------
UHM027D UHM033D UHM049D UHM067D
230V 400V 230V 400V 230V 400V 230V 400V
-----------------------------------------------------------------------------------------------------
Power in kW 18
27 36
45
-----------------------------------------------------------------------------------------------------
Inter combined AM 50 32 80 50
100 60 100 60
---------------------------------------------------------------------------------------------------------------------------
Cable section MM2 4x10 5x6 4x10 5x6 4x16 5x6 4x16
5X10
-----------------------------------------------------------------------------------------------------
