Telenav for Nextel Supported Devices: v2.1 for Motorola i88s, i58sr, i95cl User Manual

Page 10

PAGE 10 OF 30

At this point, you should press RESUME. Future invocations of the TeleNav application only require
you to press the MENU key, select JAVA APPS, highlight TeleNav, and press RUN.

If later on you want to block TeleNav’s access to GPS location fixes, you will have to change the
Privacy Setting to “Restricted”.

7. Vehicle Installation

Phone Holder

FOR SAFETY REASONS, WE STRONGLY SUGGEST USING A PHONE HOLDER TO
PLACE THE PHONE AT EYE LEVEL SO YOU CAN QUICKLY SEE THE SCREEN WHEN
NEEDED.

Follow this step only if you’ve purchased a phone holder.

Bend the phone holder into a shape that will place the magnetic holder at a comfortable viewing level,
but will not obstruct driving visibility. If possible, try bending the flexible arm into an “S”-pattern with the
bottom of the arm resting on the dashboard as shown below.

Peel off the protective paper on the suction cup, position the cup onto windshield and flip the lever up
towards the glass to create locking suction.

Use the cleaning pad to clean your phone’s battery cover on the back of the phone. Allow the cleaner
to dry completely before attaching the metal plate to the lower part of the battery cover. Peel the
protective material off of the plate, and then press it firmly in place.

NOTE – on the i95cl it is VERY important that you mount the metal plate as LOW on the back
cover as possible as shown in the TeleNav GPS Kit diagram. This is because these phones
sense a magnet in the display to determine that the phone is closed. If the metal plate is too
high, the phone holder magnet will confuse the phone into thinking that the cover is closed,
suspend the application, etc.

When parking the phone on the magnetic holder, try to place the phone as HIGH on the holder as
possible to avoid the problem described above.
