5.6.14
DNS Proxy
This feature allows the user to select the (Domain Name Server) DNS Server Priority as well as
enter IP addresses for Primary DNS and secondary DNS.
See
Fig 1-32.
Figure 1-32 : DNS Proxy
5.6.15
Easy Connect Configuration
Easy Connect feature allow user to surf web with ease without the need to changes default
configuration setting, ie TCP/IP, Proxy, DNS of user’s PC. See Fig 1-33.
There are 4 features on Easy Connect:
1. Auto IP: All valid TCP/IP setting on user’s PC can surf web via ADSL modem routers
without the need to change the IP address to the same subnet as the router or set to “Obtain
an IP address automatically”.
2. Auto DNS: Any DNS IP address set at user’s PC irregardless whether the address is valid
or invalid DNS, Auto DNS still allow user’s PC to surf the web.
3. Auto Proxy: Any valid Private IP proxy setting with any port number, ie 1234 on the web
browser such as Internet Explorer, Auto Proxy still allow PC to surf the web. Any Public
IP proxy setting will assume the proxy is valid and hence Auto Proxy function will not
take place.
Note…
The port number to be used must be specify in both the web browser and the
Auto Proxy Ports.
