PS‐7500‐DA (Double Adjustable) 2010/2011
16
Parts List:
KEY PART NUMBER DESCRIPTION
2 BD‐75XCO BODY, 7500 C/O
3 RR‐06 WIRE RING, .0625 WIRE DIAMETER X 1.900"
4 BC‐75TV‐DA BODY CAP, 7500 DOUBLE ADJUSTABLE
5 OR‐2133‐B O‐RING, BUNA, 70 DUROMETER
6 CO‐75HV COLLAR, 7500 SERIES HEAD VALVE
7 PI‐75HV‐3PORT PISTON, 7500 SERIES HV 3 PORT
8 OR‐2029‐B O‐RING, BUNA, 70 DUROMETER
9 VW‐120004‐625 WASHER, 1.200 X .004 X .625 VALVE
10 VS VALVE STACK, COMPRESSION AND REBOUND
11 SC‐75HV‐DA SCREW, 7500 DA HEAD VALVE
12 VW‐75020‐625 WASHER, .750 X .020 X .625 VALVE
13 NT‐04J JAM NUT, .625 X 18
14 OR‐5MMX1MM‐V O‐RING, 5 MM X 1 MM, VITON
15 PI‐75‐DA PISTON, 7500 DOUBLE ADJ FLOATING
16 OR‐2008‐V O‐RING, VITON, 70 DUROMETER, BROWN
17 OR‐4221‐B QUAD RING, BUNA, 70 DUROMETER
18 NE‐75X‐DA NEEDLE, 7500 DOUBLE ADJUSTABLE
19 RS‐73 REBOUND SCREW, 7300 HEX
20 BA‐093‐ST BALL, 3/32 STEEL
21 SP‐36 SPRING
22 FT‐75X‐DA FITTING, 7500 DOUBLE ADJUSTABLE
23 VW‐75‐DA WASHER, 7500 DOUBLE ADJUSTABLE
24 OR‐2011‐B O‐RING, BUNA, 70 DUROMETER
25 OR‐3MM X 1.5MM‐V O RING, 3MM X 1.5MM, VITON
26 SC‐75‐DA SCREW, 7500 DA HOL‐LOCK SOCK 500‐20
27 IU‐04 VALVE CORE, 2000 PSI
28 IU‐22‐S AIR VALVE, PORT O‐RING, S.S.
29 IU‐06 VALVE CAP, HIGH TEMPERATURE
30 OR‐2010‐B O‐RING, BUNA, 70 DUROMETER
31 SC‐75 SCREW, BUTTON HEAD 6/32 X 1/8"
32 OR‐3.5MMX1MM O‐RING, VITON
33 DO‐18 ROLL PIN, 1/16 X 1/2
34 RR‐16 RET RING, 1.025 SPIROLOC, STAINLESS
35 MO‐8T MONOBALL, .500 ID X 1.00 OD
36 SB‐765 SHAFT BEARING, 8760
37 SL‐09 SHAFT WIPER, .625 POLY (BLUE)
38 BU‐10DU10 BUSHING, DU .625 X .625
