Asus a7n8x-la (focus) motherboard 13 – Asus A7N8X-LA User Manual
Page 17
ASUS A7N8X-LA (Focus) Motherboard
13
10. Digital audio connector (3-pin ASPDIF1)
This connector is for an S/PDIF audio module that allows digital instead of
analog sound output. Connect one end of the audio cable to this connector and
the other end to the S/PDIF module.
A7N8X-LA/Focus
A7N8X-LA/Focus
Digital Audio Interface
ASPDIF1
SPDIFOUT
+5V
Ground
