Manley Langevin Dual Vocal Combo 1999 - 4/2001 LDVC000 - LDVC178 User Manual
Page 2
CONTENTS
SECTION
PAGE
INTRODUCTION 3
FRONT PANEL
4
BACK PANEL
6
MIC PRE BASICS
7
CONNECTING YOUR PREAMPLIFIER
8
OPERATION NOTES
10
SPECIFICATIONS 12
TROUBLESHOOTING 13
INTERNAL ADJUSTMENTS
15
INTERNAL LAYOUT
16
REPLACING FUSES
17
MAINS CONNECTIONS
18
APPENDIX A: WIRING YOUR OWN CABLES 19
APPENDIX B: TEMPLATE FOR STORING SETTINGS 20
